I have been in the irrigation industry since 1980 and in 1992 co-authored a book on how to easily find the flow of water available and the pressure of
the water...
Inside, are informative pages on how water works and what changes the pressure and flow of the water...
We made some charts to help see how water pressure and flow changes with elevation and pipe type and size and length...
Here are the basic limits for the flow of water you should not exceed based on pipe size:
Here is how much pressure is lost per 100 feet, based on the flow and size (and type) of pipe:
Two important facts:
You will lose less pressure by going to a larger pipe.
You will lose less pressure by reducing the flow of water.
The above water pressure loss happens as water moves through pipe (addition loss occurs when water moves through valves and fittings (elbows, tees,
etc.). These are called DYNAMIC PRESSURE LOSS.
Elevation changes also change water pressure, even when the water is not moving, called STATIC PRESSURE LOSS OR GAIN. Going downhill increases water
pressure and going uphill reduces water pressure (0.443 psi per foot):
If you need anything to help with your design, let me know!
If there is more you would like to read about, I will scan more pages from my book. It is no longer in print, but was a best seller in one
horticultural catalog for quite a while! |
